standard crimp contact AWG 24-20 socket reeled - TT9320S-H3
The precision-punched contact, made from a special brass and stainless steel, can be used in all standard housings of the Toughcon® system. It combines good electrical characteristics with a favorable price. It is
available in different coatings and packaging. A large range of conductor cross sections is available.
| contact current rating (max) | 13 A at +68°F in free air |
| contact resistance | < 5mΩ |
| insertion/withdrawal force | < 4,5N |
| connection cycles min. | 500 gilded, 100 tin-plated |
| material | brass, stainless steel |
| AWG | 24-20 |
| wire | 0,25-0,5mm² / 0.00039-0.00078inch² |
| Ø insulation diameter | 1,1 - 1,8mm / 0.04-0.07inch |
| types | pin, socket, leading pin |
| reel sizes | 5000 contacts |
Please note that contacts on a reel can only be ordered in multiples of 5,000. Please check the packing unit (reel size).
| type | socket |
| coating | gold 0.75µm |
| Download |
from 1,26 €
Price plus VAT and shipping costs
Price plus VAT and shipping costs
| from 1 | pieces | 2,77 € |
| from 10 | pieces | 1,46 € |
| from 100 | pieces | 1,26 € |
available units
29990 in stock
additional units in production
29990 in stock
additional units in production
